Used in Invisible Fence brand Powercap collars, Cameras and many other devices. The CR1/3N battery is contained inside the proprietary Invisible Fence Powercap.
Brand is JFC, Same great battery, same great price!
For use in the Invisible Fence Powercap dog collar batteries. REPLACEMENT INSTRUCTIONS *The PowerCap® battery is a proprietary casing used to house the battery that powers the collar. The CR1/3N and DL1/3N batteries are what are used inside the PowerCap®. We only sell the batteries, and not the casing. Instructions are provided as a courtesy to our customers. We are not resposible for any
● 电池型号: CR1/3N,CR11108 Li-ion锂电池
●电池类型:Li-ion锂电池
● 标准电压:3.0V;
● 终止电压:2.0V
● 额定容量:170(mAh)
● 电池尺寸: Φ11.6×10.8(mm)
● 工作温度:-10℃-+60℃;
● 存储温度:-10℃-+45℃;
● 电池极性:在底面标上“+”(“-”无标明)
● 工艺特点:采用先进的防漏液技术,配合优质的耐磨、耐高温材料,适用温度范围广,使用寿命长。具有优良的防漏性、贮存性以及锂电池固有的电压高、重量轻、体积小、比能大、电压平稳、大电流放电性能好,安全无污染等特点。 与其它品种电池相比,还具有以下特长: 1.瞬间短路后开路电压恢复较快; 2.低温性能较好,即使在-40C条件下可达常温的60%左右 3.较好的贮存性能,正常贮存是其年自放率≤2%,贮存期是普通干电池的5倍以上使用温度范围广(-20°~ +60°)。
●产品使用范围
适用范围:血糖仪测血压器,电子仪器等产品专用特殊锂电池,美容产品。
型号 | 标称 电压 (V) |
额定容量 (mAh)
|
标准放电电流 (mA)
| 最大放电电流(mA) | 最大尺寸(mm) | 重量(g) | IEC | 参考型号 | |||
连续 | 脉冲 | 直径(D) | 高度(H) | ||||||||
CR14250 | 3 | 850 | 1 | 800 | 1500 | 14.5 | 25.0 | 9.0 | CR14250 | CR 1/2AA | |
CR14505 | 3 | 1500 | 10 | 1000 | 3000 | 14.5 | 50.5 | 17.0 | CR14505 | CR AA | |
CR2 | 3 | 850 | 10 | 800 | 1500 | 15.5 | 27.0 | 11.0 | CR15H270 | CR2 | |
CR123A | 3 | 1600 | 1 | 1500 | 3500 | 17.0 | 34.5 | 16.5 | CR17345 | ||
CR123A | 3 | 1400 | 20 | 1000 | 3000 | 17.0 | 34.5 | 16.5 | CR17345 | CR 2/3A | |
CR17450 | 3 | 2400 | 1 | 1000 | 3000 | 17.0 | 45.0 | 23.0 | CR17450 | CR-AG | |
2CR5 | 6 | 1600 | 1 | 1000 | 3000 | 34.0 | 17.0 | 45.0 | 38.0 | 2CR5 | 2CR5 |
CR-P2 | 6 | 1600 | 1 | 1000 | 3000 | 35.0 | 19.5 | 36.0 | 38.0 | CP-P2 | CP-P2 |
CRV3 | 3 | 3200 | 20 | 1500 | 3500 | 28.6 | 14.4 | 52.2 | 35.0 | CRV3 | CR-V3 |
CP9V | 9 | 1200 | 1 | 150 | 300 | 26.5 | 17.5 | 49.0 | 30.0 | --- | U9VL |
CR14250E-R | 3 | 950 | 0.5 | 800 | 1500 | 14.5 | 25.0 | 9.5 | CR14250 | CR 1/2AA | |
CR14505E-R | 3 | 2000 | 0.5 | 1000 | 2500 | 14.5 | 50.5 | 20.5 | CR14505 | CR AA | |
CR17335E-R | 3 | 1800 | 0.5 | 1000 | 2500 | 17.0 | 33.5 | 20.0 | CR17335 | CR 2/3AG | |
CR17450E-R | 3 | 2700 | 0.5 | 1000 | 2500 | 17.0 | 45.0 | 24.0 | CR17450 | CR-AG | |
CR34615E-R | 3 | 15000 | 10 | 2000 | 3000 | 34.2 | 61.5 | 135.0 | CR34615 | D | |
CR425 | 3 | 25 | 0.5 | 3 | / | 4.2 | 25.9 | 0.65 | CR425 | BR425 | |
CR435 | 3 | 50 | 1 | 5 | / | 4.2 | 35.9 | 0.95 | CR435 | BR435 | |
CR535 | 3 | 80 | 1 | 7 | / | 5.2 | 35.5 | 1.40 | CR535 | BR535
|
